Association of Cone Beam CT Texture Parameters with Mandibular Bone Density and Structural Disorganization in Postmenopausal Women

Andrezza Pires da Rocha Carvalho 1
Gabriela Franco da Rosa Caetano 2 *
André Luiz Ferreira Costa 3
Márcia Oliveira de Carvalho 4 *
Kelmara Arruda Pinho 1
José Luiz Cintra Junqueira 1
Marcelo Gusmão Paraiso Cavalcanti 2
Francine Kühl Panzarella 1
1Division of Oral Radiology, São Leopoldo Mandic Faculty, São Leopoldo Mandic Research Institute, Campinas, São Paulo, Brazil
2Division of Oral and Maxillofacial Radiology, Department of Stomatology, School of Dentistry, University of São Paulo, São Paulo (SP), Brazil
3Postgraduate Program in Dentistry, Dentomaxillofacial Radiology and Imaging Laboratory, Cruzeiro do Sul University (UNICSUL), São Paulo, Brazil
4Department of Physics, Institute of Exact Sciences and Technology, University of Campinas – UNICAMP, Jundiaí, Brazil

Abstract

Objectives: This study aimed to evaluate mandibular cortical index and texture analysis parameters derived from CBCT in women of different age groups and to explore their correlation.

Methods: A retrospective observational study was conducted on CBCT scans of 66 women, divided into two groups: Group A (32–50 years, n = 33) and Group B (51–76 years, n = 33). Computed Tomography Mandibular Index (CTMI) were measured at the mental foramen region, and texture analysis was performed using the gray-level co-occurrence matrix (GLCM) to extract eleven parameters. Statistical analyses included Student’s t-test, Mann–Whitney U test, and Pearson/ Spearman correlation coefficients.

Results: The mean CTMI was 4.10 mm in Group A and 3.25 mm in Group B, indicating greater susceptibility to low BMD in group B. Group A exhibited higher AngScMom and InvDiffMom values, reflecting greater uniformity and homogeneity of trabecular structure. Group B showed higher Contrast, SumOfSqs, SumEntrp, Entropy, DifVarnc, and DifEntrp values, indicating increased variance, dispersion, and disorganization of gray-level intensities. Positive correlations were observed between CTMI and AngScMom and InvDiffMom, while negative correlations were found with Contrast, SumOfSqs, SumVarnc, SumEntrp, Entropy, DifVarnc, and DifEntrp. Patients with cortical bone thickness below 3 mm, indicative of osteoporosis, exhibited higher SumOfSqs and SumVarnc.

Conclusions: Computed Tomography Mandibular Index and texture analysis parameters are associated with bone mineral density and may serve as valuable, low-cost, and low-radiation screening tools.

Keywords: Cone Beam CT; Bone Mineral Density; Osteoporosis; Osteopenia; Texture Analysis

Citation

Carvalho APR, Caetano GFR, Costa ALF, de Carvalho MO, Pinho KA, Junqueira JLC, et al. Association of Cone Beam CT Texture Parameters with Mandibular Bone Density and Structural Disorganization in Postmenopausal Women. WebLog J Dent Oral Disord. wjdod.2026.f1105. https://doi.org/10.5281/zenodo.20951412
